JS-300 is high quality water cooling plasma power sources for CNC cutting which have high pierce capability and can achieve high verticality.
JS-300 adopts the full-bridge soft-switching technology, current can be adjustable between 70A-300A steplessly, it can make cutting operation more controllable. It is heavy duty, 100% duty circle, and built in multi protections for over current, over voltage, over air-pressure, over temperature etc, allows you to work 24 hours continuously.
Technical Parameters:
Rated Input Voltage | V | 3x380(50Hz) +/- 10% |
Rated Input Power | KVA | 57 |
Cutting Current | A | 300 |
Duty Circle | - | 100% |
Cutting Thickness | mm | 35 |
Pierce Thickness | mm | 32 |
Quality Cutting | mm | 45 |
Max. Cutting | mm | 60 |
Working Gas | - | Air/N2 |
Gas Volume | L/min | 150 |
Working Gas Pressure | MPa | 0.4 |
Cooling Method | - | Water Cooling |
Weight of Machine | kg | 110 |
Size of Machine | cm | 86x48x93 |
Cutting Parameter:
Cutting Material | Cutting Thickness (mm) | Pierce Height (mm) | Cutting Height (mm) | Cutting Current (A) | Cutting Speed (mm/min) |
Carbon steel | 5 | 5 | 4 | 105 | 3500 |
Carbon steel | 30 | 10 | 7 | 300 | 650 |
Carbon steel | 45 | Edge Cutting | 7 | 300 | 350 |
Stainless steel | 6 | 6 | 5 | 105 | 1700 |
Stainless steel | 15 | 7 | 6 | 185 | 900 |
Stainless steel | 30 | 10 | 7 | 300 | 500 |
Aluminum | 6 | 4 | 5 | 70 | 900 |
Aluminum | 15 | 7 | 6 | 185 | 900 |
Aluminum | 30 | 10 | 7 | 300 | 500 |
