JS-200 is high quality water cooling plasma power source for CNC cutting which has high pierce capability and can achieve high verticality.
JS-200 adopts the full-bridge soft-switching technology, current can be adjustable between 60A-200A steplessly, it can make cutting operation more controllable. It is heavy duty, 100% duty circle, and it has built in multi protections for over current, over voltage, over air-pressure, over temperature etc, allows you to work 24 hours continuously.
Technical Parameters:
Rated Input Voltage | V | 3x380(50Hz/60Hz) +/- 10% |
Rated Input Power | KVA | 33.3 |
Cutting Current | A | 60-200 |
Duty Circle | - | 200A/100% |
Cutting Thickness | mm | According to Material. |
Pierce Thickness | mm | 25 |
Quality Cutting | mm | 40 |
Max. Cutting | mm | 50 |
Working Gas | - | Air/N2 |
Gas Volume | L/min | 150 |
Working Gas Pressure | MPa | 0.45-0.5 |
Cooling Method | - | Water Cooling |
Weight of Machine | kg | 80 |
Size of Machine | cm | 75x38x81 |
Cutting Parameter:
Cutting Material | Cutting Thickness (mm) | Pierce Height (mm) | Cutting Height (mm) | Cutting Current (A) | Cutting Speed (mm/min) |
Carbon steel | 3 | 4 | 2.5 | 60 | 3500 |
Carbon steel | 25 | 8 | 6 | 200 | 600 |
Carbon steel | 40 | Edge Cutting | 6 | 200 | 300 |
Stainless steel | 3 | 4 | 2.5 | 60 | 1900 |
Stainless steel | 20 | 7 | 5 | 200 | 1000 |
Stainless steel | 25 | Edge Cutting | 6 | 200 | 600 |
Aluminum | 3 | 4 | 2.5 | 60 | 2500 |
Aluminum | 20 | 7 | 5 | 200 | 1100 |
Aluminum | 25 | Edge Cutting | 6 | 200 | 700 |
