JS-100N is a high quality air cooling plasma power sources for CNC cutting which has high pierce capability and can achieve high verticality.
JS-100N adopts the full-bridge soft-switching technology, current can be adjustable between 35A-100A steplessly, it can make cutting operation more controllable. It is heavy duty, 100% duty circle, and it has built in multi protections for over current, over voltage, over air-pressure, over temperature etc, allows you to work 24 hours continuously.
Technical Parameters :
Rated Input Voltage | V |
|
Rated Input Power | KVA | 16 |
Cutting Current | A | 35-100 |
Duty Circle | - | 100A/100% |
Cutting Thickness | mm | According to Material. |
Pierce Thickness | mm |
|
Quality Cutting | mm | 20 |
Max. Cutting | mm | 38 |
Working Gas | - | Air |
Gas Volume | L/min | 200 |
Working Gas Pressure | MPa |
|
Cooling Method | - | Air Cooling |
Weight of Machine | kg | 45 |
Size of Machine | cm | 62x32x60 |
Cutting Parameter:
Cutting Material | Cutting Thickness (mm) | Pierce Height (mm) | Cutting Height (mm) | Cutting Current (A) | Cutting Speed (mm/min) |
Carbon Steel | 3 | 4 | 3 | 60 | 3500 |
Carbon Steel | 20 | 7 | 5 | 100 | 700 |
Carbon Steel | 22 | Edge Cutting | 5 | 100 | 550 |
Stainless Steel | 3 | 4 | 3 | 60 | 1900 |
Stainless Steel | 20 | 7 | 5 | 100 | 700 |
Stainless Steel | 22 | Edge Cutting | 5 | 100 | 650 |
Aluminum | 3 | 4 | 3 | 60 | 2500 |
Aluminum | 18 | 7 | 5 | 100 | 850 |
Aluminum | 22 | Edge Cutting | 5 | 100 | 750 |
