Tank-210 is our latest research and development for dry cutting and water mist cutting dual-use plasma cutting machine, has high pierce capability and can achieve high verticality.
Tank-210 adopts the full-bridge soft-switching technology, current can be adjustable between 35A-210A steplessly, it can make cutting operation more controllable. It is heavy duty, 100% duty circle, and it has built in multi protections for over current, over voltage, over air-pressure, over temperature etc, allows you to work 24 hours continuously.
Technical Parameters:
Rated Input Voltage | V | 3x380(50Hz/60Hz) +/- 10% |
Max Input Power | KVA | 46.2 |
Cutting Current | A | 35-210 |
Duty Circle | - | 210A/100% |
Cutting Thickness | mm | According to Material. |
Pierce Thickness | mm | 35 |
Quality Cutting | mm | 45 |
Max. Cutting | mm | 55 |
Cooling Method | - | Water Cooling |
Weight of Machine | kg | 115 |
Size of Machine | cm | 89x56x99 |
